MYCOM "O" profile reduces the rotor interlobe gas blow-by and improves sealing oil film on rotor surface by use of a circular arc profile rather than the conventional sealing edge.

• Broad range of models from 125mm (276CFM) to 400mm (8,120CFM)
• Low porosity cast iron, ANSI/ASHRAE STD. 15, hydraulically tested at 470Psig after assembly
• Steal-backed babbitted-sleeve type for Radial Bearings
• Angular contact ball bearings with oversized balance piston for Thrust Bearings
• Variable Vi
• Capacity control by a hydraulically-operated slide valve
